Product Details:
|
| Type: | Other, Dome/ Vertical | Use: | FTTX ODB NAP FTTH |
|---|---|---|---|
| Warranty Time: | 3 Year | Network: | Wireless Lan, ONVIF, None, TCP, Ip, Wifi, 4g, 3G |
| Product Name: | Fiber Optical Closure | Application: | FTTH |
| Installation: | Aerial/ Direct Burial/ Duct Mounting | Function: | Distribution Fiber System (FTTH) |
| Weight: | Variable | Ports: | 1 Uncut, 7 Branch, 2 Drops |
| Max Cores: | 144 (A), 360(B), 648(C) | Warranty: | 10 Yeas |
| Keywords: | Fiber Optical Closure | Port: | Ningbo Or Shanghai |
Style | Dome/ Vertical | ||||||
Dimensions (H*D) | 625 × Φ270 mm | ||||||
Material | PP+GF | ||||||
Sealing Type | Mechanical Seal | ||||||
Protection Grade | IP68 | ||||||
Cable Ports | Uncut | Oval | 1 | Φ8 - Φ18 mm | |||
Branch | Round | 7 | |||||
Drop | 2 | ||||||
Fiber Splice Capacity | 648 | ||||||
Tray Capacity | 12 | ||||||
Tray Count | 60/ 120 | ||||||
PLC Splitter | 1:4 Mini | 2 PCS | |||||
1:8 Mini | 1 PC | ||||||
Weight | 9.5 - 12.0 kg | ||||||
Application | Aerial/ Direct Burial/ Duct Mounting | ||||||
Packing Type | Inner Carton | 650×315×280 (1 PCS) | |||||
Outer Carton | - | ||||||
