FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black

FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black

Large Image :  FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black

Product Details:
Place of Origin: Zhejiang, China
Brand Name: customize
Model Number: 16 cores fiber optic distribution box
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: $6.90/pieces >=50 pieces
Packaging Details: blister packing >carton box>outer carton box
Supply Ability: 400000 Piece/Pieces per Month
Contact Now

FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black

Description
Type: Fiber Optic Terminal Box Use: FTTX ODB NAP FTTH
Warranty Time: 3 Year Network: Wireless Lan, Wired LAN, None, GPRS, Wifi, 4g
Product Name: 16 Cores Fiber Optic Distribution Box Application: Telecommunication
Material: PP Dimensions: 295*190*110mm
Function: Distribution Fiber System (FTTH) Color: BLACK
Weight: 1.505kg Max Capacity: 24 CORES
Keywords: 16 Cores Fiber Optic Distribution Box Reinforced Adapter: 16 Pcs Of SC/UPC Or SC/APC
Port: Ningbo Or Shanghai

Description:
This product integrates the splitting and distribution function in one distribution box. So that it can realize the splicing and
branch of the optical cable. The unique design of the box-shaped structure of this box can be used as a fiber splitting or splice box, and the 3 layers structure, easy for future expansion and maintenance. It is suitable for the cable connection of the optical communication equipment. And this product is for aerial stand-mounts FTTH drop location where drop cables are spliced to distribution cables. It can keep internal components. Away from outdoor environmental damage. Its flexible configuration supports 3 cables in and 3 cables out. Good performance is useful in harsh environment. 16 pcs of adapters can be installed, and through the adapters of the distribution box, the signal is drawn by the optical fiber jumper to realize the optical fiber distribution function. Also suitable for fiber cable and pigtails protective connection.

Features

• The closure casing is made of industrial plastic PP
• Outdoor application and good UV resistance
• Double sided drop cable outlets drop, cable can lead in at both sides, easy to deploy
• 6 cable ports entrance, 2 for feeder cable (8-20mm) and 4 for branching cable(5-16mm)
• 3 layers structure, easy for futur expansion and maintenance
• Fiber bend radius control more than 40mm.
• 180 degree access with buckled lock structure.
• Protection grade IP-65
• 16 pcs adapters for SC.
• The application on NAP in the distributed split PON architecture

Specification
Material
PP
Size
295×190×110mm
Max splice
24 cores
Number of Adapters
16 pcs of SC/UPC or SC/APC
Weight (g)
1505g
Color
Black
Cable entrance
3 in/3 out
Product Description
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 0
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 1
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 2
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 3
Main Products
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 4
Mini Type PLC Splitter
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 5
Cassette Type PLC Splitter
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 6
Rack Mounted Type PLC Splitter
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 7
Insertion Type PLC Splitter
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 8
Tray AssemblyType PLC Splitter
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 9
Other goods
Company Profile
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 10
Company Profile
Ningbo Kehao Hanxing Photoelectric Technology Co., Ltd was founded in 2002, which has been focusing on the field of optical and electrical communications for 20 years.
As the founders, the couple Chen Bo and Reng Chunfei started their own business at the beginning and now the team has 500 members.
1.Factory Direct, Best Price
At the same price, we offer the highest quality products. 2.Delivery Time: 7-10 Days
The company has a large number of stable employees over ten years. To ensure that the delivery time can be guaranteed at any time.
3.High Quality:
IQC-PQC-FQC-OQC.100% qualified. 4.Satisfactory Service:
Special team responsible for after-sales service,Includes installation instructions and technical support.Response within 1
hour,solution within 8 hours, after -sale service
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 11
Production Workshop
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 12
Product packaging
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 13
Why Choose Us
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 14
FAQ
Q1. Can I have a sample order for this product? A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable. Q2. What about the lead time? A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than Q3. Do you have any MOQ limit for sample order? A: Low MOQ, 1pc for sample checking is available Q4. How do you ship the goods and how long does it take to arrive? A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional. Q5. How to proceed an order for the product? A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production. Q6: Do you offer guarantee for the products? A: 30 Years' Guarantee for fiber optic PLC splitter 25 Years' Guarantee for fiber optic cable
FTTX Pole Mounted 16 Cores Fiber Optic Splice Closure/ Distribution Napbox Black 15
